Mamiya Lens Tests by Tony Howell

Back to lens tests main page

Phase One LogoPhase One 645AF

Camera used for these tests

Phase One 645AF (same as Mamiya 645AFD III) with P45 digital back 39 Megapixels resolution

Produces 112mb (8 bit) files suitable for huge prints.

Manually-focused images using Mamiya FD 402 focus magnifier, tripod, no wind, bright but overcast. I used glasses but am not great at focusing (long sighted!). I still prefer it to AF though. Mamiya Electronic release used. I'm not technically-minded, I'm only interested in how lenses perform in real situations. These tests are not comprehensive, but will hopefully help anyone interested in buying these products, or anyone who already owns them but hasn't tested them yet (why haven't you!). I'm just sharing this information because I looked for it on the web, but couldn't find enough about these lenses. Mamiya lenses are excellent if you understand how to get the best from them, and they're at bargain prices on the used market.


Mamiya 55-110mm f4.5 for 645AF

Brief Summary: - Zoom lens with good resolution, average corners, centre best at f8. CA (Chromatic Aberration) in corners at all apertures but easily removed with software. Fairly poor wide open at f4.5 with a 'milky' quality. Best in the middle to end of the zoom range. Poorer at 55mm than 110mm. A lens I did use a fair bit with it's useful zoom range, but could be much better 6/10.

55-110mm

Okay, here's the subject I used to do this brief test at 110mm

Lens Test

Centre at f8 (a little down from centre). The best result from this lens. Compared to the best lens I own (Mamiya 120mm macro) this is very close, a significant result: -

Lens Test


Centre at f22. Contrast, colour and sharpness somewhat lost due to diffraction, CA visible
above the white line, milky smudged quality : -

Lens Test

Centre at f4.5. Contrast and sharpness lost, bad CA visible above the white line, colour
okay, milky smudged quality exaggerated. Unusable: -

Lens Test

Bottom Left Corner at f8 (still in the zone of sharp focus). A good result: -

Lens Test

Bottom Left Corner at f22, still good, but contrast and sharpness somewhat lost
to diffraction, slight CA visible (a cyan line) on l/h side of the number 4 : -

Lens Test

Bottom Left Corner at f4.5, strangely good as it's better than the centre result, but contrast and sharpness somewhat lost due to large aperture, no CA visible: -

Lens Test

The bottom right corner showed similar results to the ones above.

Top left corner at f8 (out of the zone of sharp focus). Good: -

Lens Test

Top left corner at f22, sharper due to the small aperture. A very good result which
surprised me. I thought diffraction would rob this section of sharpness and I was wrong : -

Lens Test

Top left corner at f4.5, to be expected: -

Lens Test

I would recommend this lens for smaller sensors/film, it has a good range and works fine at f8-f11 which is
what I used it at most of the time on a tripod. My sensor is out-performing the lens though. If you happen to be using a large sensor I'd recommend using Mamiya's prime lenses instead, or.....I've just bought a Phase One 75-150mm D lens, which in my limited use so far blows this one out of the water. Test to follow, and my 55-110mm
will have to go. Watch this space!

Here's a few recent shots followed by 100 % crops: -

Winter Trees

1/30th, f11 ISO100, 55-110mm at 55mm, tripod.
100 % crop: -

Winter Trees

Clevedon

1/20th, f11 ISO 50, 55-110mm at 65mm(?), tripod.
100 % crop: -

Clevedon

I would recommend doing your own tests with all your lenses. I learn a lot from doing this, and know what to expect from this lens when out in the field.
